Highly Efficient Vibrating Screen Usage in Grain Cleaning Machine

Today, let's discuss about the highly efficient vibrating screen usage in grain cleaning machine. Highly efficient vibrating screen is the ideal equipment for grain cleaning machine. ...

Today, let's discuss about the highly efficient vibrating screen usage in grain cleaning machine.

Highly efficient vibrating screen is the ideal equipment for grain cleaning machine. It is necessary to prepare the screening process in corn and grain processing. Highly efficient vibrating screen vibrates with low amplitude and high vibration frequency which can accelerate the layering on the sieve and the speed of passing the mesh and improve screen production rate and screening efficiency.

Grain cleaning machine with highly efficient vibrating screen can remove large and medium impurities on the first and second layers of screen and the small impurities on the third layer of screen. It can clean the large and small impurities once and the screen size is comparatively small, which can reduce the floor space of the whole grain cleaning machine and its height. It also saves lots of energy consumption and operation and maintenance cost. Therefore, highly efficient vibrating screen has positive effect on grain cleaning machine technology improvement.

The highly efficient vibrating sifter is employed for cleaning and classification in flour milling, oil expression, rice milling, animal feed, food processing and chemical industry or in grain storage facilities (silos). With its different specification of sieve desks, highly efficient vibrating sifter can remove coarse and fine impurities from wheat, corn, rice, oilseed etc, which makes it ideal equipment for small and medium-sized food processing plants.

The materials go into decentration cone hopper (6)through inlet pipe(5);then get in the middle of material plate(9)of the box(8) through cloth(4).The box vibrates with sieve to scatter the materials uniformly to the total width of the sieve on the bottom plate (11). If the materials are not even-distributed,the adjusting plate (7)makes the feed charge in an ideal state.

The pressure door (10)is installed on the joint of box and sieve,which makes the materials uniformly scatter at the same hight.The materials go through the pressure door and sprinkle on the first sieve(3) with big impurities on ,which are discharged through the side outlet(1).

The mixture below fall on the second sieve (2) with small impurities below falling on the bottom plate (12) to go out through outlet(13).The mixture on the second sieve is discharged through pressure(14) to vertical air suction separator (15),which is adjustable with the handle (16) to excellently separate the materials by switching the air door to proper position.
